The template context

When you generate code, Restorm passes your entire design to the template as a ctx object. Your models, your enums, your routes and above all their intentions (searchable, PII, cache, and the model’s whole operational profile: volume, access pattern, traffic, freshness, sensitivity, retention) are there — a template reads them to decide what to generate. No variable needed for that: the information you’ve already entered in the design is directly available.

The shape of ctx

ctx
├─ design        # name, version, description, basePath, defaultAuth, vars
├─ enums[]       # name, description, values[]
├─ models[]      # name, description, inherits, identifier, timestamps, softDelete,
│                # volumetry, accessPattern, traffic, freshness, sensitivity,
│                # retention, properties[], allProperties[], examples[], vars
└─ groups[]      # name, basePath, versionPrefix, headers[], routes[]
     └─ routes[] # method, path, fullPath, params[], body, responses[],
                 # auth, pagination, cacheSeconds, idempotent, deprecated, vars

References are by name (never by internal identifier): property.enum is the enum’s name, property.references.model the name of the target model, model.inherits the parent’s name. On a model, properties[] lists its own properties (for the type declaration) and allProperties[] the own + inherited, flattened properties (for a complete instance: example data, SQL columns, request body).

Reading a flag: the golden rule

Boolean flags are present in ctx only when they are enabled. The engine renders in StrictUndefined: so you must test for the presence of the key, never its value.

{# ✅ correct — testing for presence #}
{% if 'searchable' in p %}INDEX({{ p['name'] }}){% endif %}

{# ❌ wrong — raises an error when the flag is absent #}
{% if p.searchable %}…{% endif %}

Only property.required (boolean) and route.auth (enumeration) are always present. The other boolean flags are “present = true”; the value fields (volume, operational profile, cache…) carry their value when they’re filled in, and are absent otherwise — same presence rule.

On a property	On a model	On a route
readOnly · writeOnly · nullable	timestamps · softDelete (booleans)	idempotent · deprecated (booleans)
unique · searchable · immutable · pii	Operational profile (values): volumetry · accessPattern · traffic · freshness · sensitivity · retention	cacheSeconds (number) · pagination (object)

A model’s operational profile values: accessPattern (readHeavy / writeHeavy / balanced / appendOnly), traffic (low / medium / high), freshness (strong / shortCache / longCache), sensitivity (public / internal / confidential / pii), retention (permanent / archivable / ephemeral), volumetry (hundreds / tenThousands / millions).

Note

Always access keys with bracket notation (p['name'], route['vars']): the context is passed as plain dictionaries, so example.values would call the dict’s values method instead of your key. See the portability rules.

Example: caching read-heavy data

Two cases, depending on whether the information already exists in the design or not.

a) The design already carries the info

If you’ve set a cache duration on a route, it arrives in route['cacheSeconds']; route['idempotent'] tells you it’s safe to cache (read-only):

{% for group in ctx['groups'] %}
{% for route in group['routes'] %}
{% if 'cacheSeconds' in route and 'idempotent' in route %}
// {{ route['method'] }} {{ route['fullPath'] }}
app.use("{{ route['fullPath'] }}", cache({{ route['cacheSeconds'] }}));
{% endif %}
{% endfor %}
{% endfor %}

b) “Read-heavy” is a native field of the model

No variable needed: “read-heavy” is directly the model’s access pattern. In the model’s settings, Operational profile group, you choose Read-heavy — the template reads it in model['accessPattern']. Combine it with model['freshness'] (freshness tolerance) to decide whether to cache, and for how long:

{% for model in ctx['models'] %}
{% if model['accessPattern'] == 'readHeavy' and model['freshness'] != 'strong' %}
{% set ttl = 3600 if model['freshness'] == 'longCache' else 60 %}
registerCache("{{ model['name'] }}", {{ ttl }});   // cache enabled ({{ ttl }}s)
{% endif %}
{% endfor %}

Note the != 'strong' test: a read-heavy model but with strong consistency must not be cached. That’s the whole point of having both intentions side by side in the design.

Reserve generation variables for what the design doesn’t already carry (a template-specific setting): the business intentions — volume, access pattern, traffic, freshness, sensitivity, retention — are native fields of the model.

The full contract

This context is versioned (ctx['contextVersion']) and described exhaustively by a JSON-Schema shipped in the application repository (docs/contributing/design-codegen-context.schema.json) — copy it into your template so its CI validates the reference context. An AI agent gets the same contract on the fly via the MCP tool get_design_template_contract.
